2HL/2HM/2HN
1-5-37
6. Remove the each three screws and then
remove the laser scanner unit (MC,YK).
7. Check or replace the laser scanner unit and
refit all the removed parts.
Figure 1-5-53
Screw
Laser
scanner
unit
Screw
Screw
Laser scanner unit MC
Screws
Screws
Laser scanner
unit YK
Screw
Screw
