Kyocera FS-C5300DN Service Manual

2HL/2HM/2HN
1-2-3
Figure 1-2-3 120 V AC model
11
2
3
4
5
2
3
4
5
13
15
16
17
18
19
13
1
14
12
6
7
8
9
10
21/23 ppm
(250-sheet) model
21/23 ppm
(500-sheet) model
26/28 ppm
(500-sheet) model
26/28 ppm
(500-sheet) model
21/23 ppm
(500-sheet) model
21/23 ppm
(250-sheet) model
1. Printer
2. Toner container (Yellow)
3. Toner container (Black)
4. Toner container (Cyan)
5. Toner container (Magenta)
6. Waste toner box
7. Power cord
8. Document tray
9. Upper left cushion
10. Upper right cushion
11. Outer case
12. Machine cover 600 x 600 x 900
13. Cassette cushion
14. Desiccating agent
15. Main pad
16. Machine cover 650 x 650 x 1200
17. Bottom left cushion
18. Bottom right cushion
