2HL/2HM/2HN
1-3-16
Service items Description
No. Items Description
(7)
cont.
(c) Detail of paper source (Hexadecimal)
00: MP tray
01: Paper cassette 1 (printer)
02: Paper cassette 2 (paper feeder 1)
03: Paper cassette 3 (paper feeder 2)
04: Paper cassette 4 (paper feeder 3)
05: Paper cassette 5 (paper feeder 4)
06: Paper cassette 6 (paper feeder 5)
07: Duplex unit
08: Bulk paper feeder
09: Envelope feeder
(d) Detail of paper size (Hexadecimal)
01: Monarch
02: Business
03: International DL
04: International C5
05: Executive
06: Letter-R
86: Letter-E
07: Legal
08: A4R
88: A4E
09: B5R
89: B5E
0A: A3
0B: B4
0C: Ledger
0D: A5R
8D: A5E
0E: A6
0F: B6
10: Commercial #9
11: Commercial #6
12: ISO B5
13: Custom size
1E: C4
1F: Postcard
20: Reply-paid post-
card 21: Oficio II
22: Special 1
23: Special 2
24: A3 wide
25: Ledger wide
26: Full bleed paper
(12 × 8)
27: 8K
28: 16K-R
A8: 16K-E
32: Statement-R
B2: Statement-E
33: Folio
34: Western type 2
35: Western type 4
(e) Detail of paper type (Hexadecimal)
01: Plain
02: Transparency
03: Preprint
04: Labels
05: Bond
06: Recycle
07: Vellum
08: Rough
09: Letter head
0A: Color
0B: Prepunched
0C: Envelope
0D: Cardstock
0E: Coated
0F: 2nd side
10: Media 16
11: High quality
15: Custom 1
16: Custom 2
17: Custom 3
18: Custom 4
19: Custom 5
1A: Custom 6
1B: Custom 7
1C: Custom 8
(f) Detail of paper exit location (Hexadecimal)
01: Face down tray (FU)
02: Face up tray (FU)
03 to 48: Reserved
(8) Service Call (Self diagnos-
tic error) Log
# Count. Service Code
Remembers 1 to 8 of
occurrence of self diag-
nostics error. If the
occurrence of the previ-
ous diagnostics error is
less than 8, all of the
diagnostics errors are
logged.
The total page count at
the time of the self
diagnostics error.
Self diagnostic error
code
(See page 1-4-3)
Example
01.6000
01 means a self-diag-
nostic error; 6000
means a self diag-
nostic error code.
To Next Page
