Kyocera FS-C5300DN Service Manual

2HL/2HM/2HN
1-3-15
Service items Description
No. Items Description
(7)
cont.
(b) Detail of jam location
Figure 1-3-7
Registration sensor
Paper exit sensor
Duplex conveying
sensor
Paper full sensor
PF paper feed sensor
26/28 ppm (500-sheet) model
21/23 ppm (500-sheet) model
21/23 ppm (250-sheet) model
Sensors
MP tray
Cassette 1 (printer)
Paper feeder 1
Paper feeder 2
Paper feeder 3
Printer inside
Paper exit section
Duplex section
Paper jam location
