2HL/2HM/2HN
1-5-8
1-5-3 Paper feed section
(1) Detaching and refitting the paper feed roller assembly (paper feed roller and pickup roller)
Procedure
1. Remove the cassette.
Figure 1-5-8
Cassette
Cassette
26/28 ppm (500-sheet) model
21/23 ppm (500-sheet) model
21/23 ppm (250-sheet) model
