2HL/2HM/2HN
1-5-18
6. Remove the intermediate transfer unit.
7. Check or replace the intermediate transfer
unit and refit all the removed parts.
Figure 1-5-20
Guide
Guide
Projection
Projection
Intermediate transfer unit
Intermediate transfer unit
Intermediate
transfer unit
