Fax Operation (Names of Parts / Preparations / Features and Functions of this Fax)
1-2
Names of Parts
Main Body Parts
The following contains information on the names when this machine is used as a facsimile.
Refer to the Operation Guide for your machine for information on other parts of this machine.
1 Operation panel
2 Line jack (L)
3 Telephone jack (T)
4 Power switch
IMPORTANT: Be aware that fax transmission/reception will not be available if the power switch is
turned OFF ({). To continue to allow fax communication, turn the power off by pressing the Power
key on the operation panel.
Document Processor
This unit is a duplex document feeder from which you can fax both 1-sided and 2-sided originals.
5 Document tray
6 Document insert guides
7 Document Processor cover
8 Document eject table
9 Document Processor open/close lever
10 Document set indicator
5
67
8
9
3
10
2
1
4
2
