Kyocera MA2000 - Page 157

9-17
Troubleshooting
3 Pull up the drum unit lever, and remove the drum unit.
4 Push up the release lever, and then move the paper feed roller to the right..
5 Remove the paper feed roller.
Note The drum unit is sensitive to light. Never expose the drum unit to light for more than five minutes.
1
2
12
