3-1
3 Preparation
Connections
This section explains how to start up the machine.
Connecting the USB Cable
Follow the steps as below for connecting the USB cable.
1 Connect the USB cable to the machine’s USB interface connector.
2 Connect the other end of the USB cable to the computer's USB interface connector.
Connecting the Power Cord
Install the machine close to an AC wall outlet. If an extension cord is used, the total length of the power cord plus extension
should be 5 meters (16 feet) or less.
1 Connect the power cord to the power cord connector at the rear of the machine.
2 Connect the other end of the power cord to a power outlet.
Note Use a USB cable with a rectangular Type A plug and a square Type B plug.
The USB cable should be shielded and no longer than 5 meters (16 feet) long.
Note Only use the power cord supplied with the machine.
To Next Page
