Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
3 Go to next step according to result of height and level check.
• Height OK, Level OK: Go to step 131.
• Height OK, Level NG: Go through from step 122 to 124 then jump to step 126.
• Height NG, Level OK: Go to step 122.
• Height NG, Level NG: Go to step 122.
124
Open the front cover [A].
• The evenness has to be checked by leveler in the end.
[E]
[F]
OK : [E]=[F]
NG : [E]>[F],[E]<[F]
To Next Page
