T / S1 contacts (Trip contacts) - 1a Contacts
Rated Power
AC 250V, DC 125V
Continuous Flow
Electricity Capacity
20A (AC 250V)
0.5 sec. Close
Circuit Capacity
30A (DC 125V)
Closing Capacity
6250VA
Material
Silver alloy
T / S2 ~ T / S5 Contacts (Signal contacts) - 4a Contacts
Rated Power
AC 250V, DC 125V
Continuous Flow
Electricity Capacity
5A (AC 250V)
0 . 5 s e c . C l o s e
Ci rc ui t Capac i ty
5A (DC 125V)
Closing Capacity
1250VA / 150W
Material
Gold-plate silver alloy
Healthy Alarm - 1b Contact
Rated Power
AC 250V, DC 125V
Continuous Flow
Electricity Capacity
10A (AC 250V)
Open Circuit
Capacity
DC 125V, 30W, Time constant(25ms), 1A
Closing Capacity
2500VA / 300W
Material
Silver alloy
【Table 2.5】 Output Contacts / Capacity
2.6 Output Contacts / Capacity
