Press Key in self-diagnosis screen, then it will exit this menu and convert to the
upper menu.
6.2.4 RS-485 Comm. Setting
It is a category to set the communication setting, and it can set Baudrate and Slave
Addr.
Selecting( ) 4. RS-485 Comm. category in Setting will display the following screen.
－
〉
R
S
-
4
8
5
C
o
m
m
.
1
.
P
r
o
t
o
c
o
l
:
M
o
d
B
u
s
*
2
.
B
a
u
d
r
a
t
e
:
1
9
2
0
0
3
.
S
l
a
v
e
A
d
d
r
:
1
Press Key in RS-485 Comm. screen, then it will exit this menu and convert to the
upper menu.
Category
Range
Default
Value
Description
Protocol
MODBUS
MODBUS
Communication Protocol
Baudrate
300, 600, 1200, 2400,
4800, 9600, 19200 (bps)
19200
Set the communication
speed
Slave Addr
1~254
1
Set Slave Addr
【Table 6.3】 RS-485 Comm. Setting
6.2.5 System Config. Setting
System Config. has detail categories of Power system, T/S Output, and Password.
Selecting( )5. System Config. category in Setting will display the following screen.
－
〉
S
y
s
t
e
m
C
o
n
f
i
g
.
1
.
P
o
w
e
r
S
y
s
t
e
m
*
2
.
T
/
S
O
u
t
p
u
t
3
.
P
a
s
s
w
o
r
d
