Digital UnderVoltage Relay (GDR-D01) User's Manual V1.10
34 / 47
Kyongbo Electronics Co., Ltd.
Default
Screen
Setting
(Menu)
1. Measurements
Va
2. Protection
1. UVR
1. Mode
OFF, NI, DT
2. PickUp
30~105V (1V Step)
3. Time Dial
0.1~10.0 (0.1Step)
4. DT_Time
0.04~60.00Sec (0.01Sec Step)
5. OP_MODE
DIGITAL, INDUCTION
6. RST_MODE
ON, OFF
7. RST_TIME
0.1~180.0Sec (0.1Sec Step)
3. Self-Diagnosis
Power Fail, CPU Watchdog,
CPU Memory, Setting
4. RS-485
comm.
1. Protocol
MODBUS
2. Baudrate
300, 600, 1200, 2400, 4800,
9600, 19200 (bps)
3. Slave Addr
1~254
5. System
Config
1. Power
System
1. FREQ
50Hz or 60Hz
2. P_PT_RAT
0.1~3200.0:1 (0.1 Step)
2. T/S
OutPut
1. T/S
1~5
1. CON
OFF, UVR
2. RST
SELF or MANUAL
3. DLY
0.00~60.00Sec (0.01Sec Step)
3. Password
New Password : ****
6. Recorder
1. Display Faults
Counter, Element, Time, Va
2. Clear Faults
Clear All Faults? Yes or No
7. Test
1. Display Test
Are you sure to Display Test?
Yes or No
2. Contact Test
T/S 1~5,H.Alarm : on or off
【Table 6.5】 Setting Menus
