10

① LCD
Fieldeffectliquidcrystaldisplaywithmaximumindicationof 1999 .
Functionsymbol(mA,A)anddecimalpointautomaticallyappearas
thefunction/rangeswitchisturned.
  B  is displayed on the lower left corner for low battery warning
and  1  is displayedonlyatthehighestdigitforoverrange
indication.
② DataHoldButton
Allowsfor easyreading in dimlylit orhard-to-reach-locations. The
displaycanbeobservedawayfromtheconductorafterpushingin
thebutton.Dataholdcanbereleasedbypushingthebuttonagain
afterthereadingistaken.
③ Two-wayAnalogueOutputTerminal
ACcurrentpickedup by transformer jaws( 7 )isconvertedand
outputas AC andDCvoltage output. (SeeAnalogueOutput in
section 3 ,Specifications.)InsertoutputcordModel 7073 intothis
terminalfor monitoringwaveform withan oscilloscope,making
RMSmeasurementsorconnectingtoarecorder.
④ SafetyHandStrap
preventstheinstrumentfromslippingoffthehandduringuse.
⑤ PowerFunction/RangeSwitch
Selectionfunctionandrange.Itisalsousedtoturnpoweronoroff.
#
 CAUTION
AlwayssetthePowerFunction/RangeSwitchtotheOFFposition
afteruse.
⑥ JawTrigger
Operatestransformerjaws( 7 ).Presstoopenthejaws.
⑦ TransformerJaws
Pickupthecurrentflowingthroughtheconductor.
⑧ PeakHoldSelectorSwitch
Selects 10 msor 100 msresponsetime.Settheswitchbacktothe
OFFpositiontoreleasepeakholdormakenormalmeasurements.
⑨ FrequencySelectorSwitch
Makesfrequencyresponseselection.
⑩ Barrier
Itisapartprovidingagainstelectricalshockand ensuring the
minimumrequiredairandcreepagedistances.
