５−５ How to Use Data Hold Function
Pushin theData Hold button to freeze the reading. This isespecially
usefulfortakingareadinginadimlylitorhard-to-reachlocations.The
displaycan be observedawayfrom theconductor.Push thebutton
againtoreleasethereading.
５−６ Analogue Output: How to Use Model 7073 Output Cord
AC and DC output can be obtained by inserting optional Model 7073 
outputcordintothetwo-wayanalogueoutputterminal( 3 ).
ACOutput
Canbemonitoredbyconnectingadigitalmultimetertoanalogueoutput
terminalorobservedasawaveformbyconnectinganoscilloscope.
For trueRMSmeasurements,connect a true-RMS-readingdigital
multimeter.
DCOutput:
Canbe monitoredby connectinga digitalmultimeter, or arecorder,
whichenablesmanyhoursofmonitoring.SeeFigure 8 .Withthe 2413 F
inthe peak hold mode, DC voltage correspondingto 1 / √ 2 of a peak
currentvaluecanbeheldandoutput.
Refertosection 5 - 3 ,HowtoUsePeakHoldFunction.
