―20―
9-4AdaptorsfortheEarthcordandreplacement
1.Adaptors
MODEL7131: Safetyalligatorclip
ConnectedtotheEarthterminaloftheEarthterminalboard.
MODEL7161: Testbar
Connectedtotheearthsideoftheoutlet.
2.HowtoreplaceAdaptors
Toremovetheadaptors,pullthemout.Thenfirmlyattachthe
adaptorasdesiredtothetipoftheEarthcord.
Female
Screw
MaleScrew
Prod
PickelProd
ExtensionProd
HexagonalHole
9-3Testprodsandreplacement
1.TypesofTestprods
MODEL8072: StandardTestprod
Usedforordinarymeasurement.
(AttachedtotheLineprobeatthetimeofpurchase.)
MODEL8017: Extensionprobe
Usedindifficult-to-reachsituations.
MODEL8016: Pickleprod(Optional)
Usedtohooktheprobeonaconductor.
2.HowtoreplaceTestprod
To remove the Test prod, turn the cap of LINE probe
counterclockwise.Insertthethreadedendofanotherprodintothe
hexagonalholeontheprobecapasshown.Then,turntheprobe
capclockwisetosecureitonthebodyoftheprobe.
Fig.16
Fig.17
Safetyalligatorclip
Testbar
DANGER
¡Disconnectthetestleadsfromtheinstrumentbeforereplacing
thetestprodsoftheLineprobeortheadaptorsoftheEarth
cordinordertoavoidapossibleelectrichazard.
