L-3 TECHNOLOGIES ESI-500 - Page 16

ESI-500
Pilot’s Guide1-6
Description
Slip Accuracy: Accuracy +/-2°. No turn rate, no standard
turn bank angle. Release 1.1 the Range is
+/- 12° Release 1.2 and greater the range
is configurable at installation for +/- 7° or
+/- 12°.
Heading: Normal Performance for MAG-500 Installa-
tion
• Static heading error will not exceed
+/-2.0°
• Dynamic heading error will not exceed
+/- 6.0°
Degraded Performance for MAG-500
Installation (when the “HDG DEGRADED”
indication is shown)
• Static heading error will not exceed
+/- 12.0°
• Dynamic heading error will not exceed
+/- 24.0°
Latitude limits: +/- 70°. Dip angle exclusions
for Northern Canada and South of Australia.
The heading will fail if the magnetic dip an-
gle exceeds 82°.
When installed with External 429 Heading,
performance is based on External LRUs
performance requirements. Display error for
external heading is within +/- 1.0° of heading
source.
Attitude: Normal Performance
• Static pitch or roll ±1.0°
• Dynamic pitch or roll ±2.5°
Degraded Performance (when the “ATT
DEGRADED” indication is shown)
• Static Pitch +/-3° and Roll +/- 4°
• Dynamic Pitch Accuracy is less than or
equal to +/-6.0° in the range of +/-10.0°
and outside of +/-10.0°, the pitch is in the
correct direction.
• Dynamic Roll Accuracy is less than or
equal to ±8.0° in the range of +/-25.0°
and outside of +/-25.0°, the roll is in the
correct direction.
Pitch, Roll, Yaw Rate: +/- 300°/second
Specications (Continued)
