ESI-500
Pilot’s Guide 1-5
Description
Specications
GENERAL
Weight: 2.75 Lbs (1.25 kg) MAX
View Area and
Angles:
Display has a viewable area of 3.5 in diago-
nal (70.56mm x 52.92mm)
Primary viewing angle range of +/- 35° in the
horizontal plane and -20/ +30° in the vertical
plane.
NVIS Capable: The display and bezel lighting are compati-
ble with NVIS lighting systems.
DISPLAY RANGE
Attitude: Pitch +/- 90°, Roll +/-180°, Yaw 0° to 360°
Altitude: Tape and Digital Readout range (-1,500 to
35,000 ft.)
Metric Readout range (-456 to 10,668 m)
Airspeed: Tape Viewable Range: 80 units (kts / mph)
Tape and Readout Limit, 20 to 300 kts (23 to
345 mph)
Baro Value: InHg: (16.00 to 32.50) STD 29.92
HPA: (542 to 1,100) STD 1013
MB: (542 to 1,100) STD 1013
OPERATION LIMITS
Vertical Speed: Altitude Rate up to ± 9,900 ft/min
Computed Airspeed: Up to 300 kts (345 mph)
6. For installations with a MAG-500, the Heading Degraded
operation occurs if the Roll value is greater than 11.5° for three
minutes, or if the “ATT DEGRADED” indication is shown. The pilot
is alerted to this degraded mode of operation by an amber “HDG
DEGRADED” indication on the display.
• Heading information continues to be shown, but at a lesser
performance.
• When air data is failed, heading is invalid.
