ESI-500
Pilot’s Guide3-12
Display Features
Navigation
If congured, navigation information is located in the lower portion of
the display, above the heading tape. The Pilot menu is used to enable
or disable navigation information from the display.
Navigation data is removed when the Pilot menu is active, when
aligning attitude, or if aircraft pitch has met or exceeded +30° or -20°,
or roll has met or exceeded +/- 55°.
The display of VOR data consists of a Navigation Source, Selected
Course, TO/FROM indicator, and Lateral Deviation Scale. See Figure
3-10.
The display of ILS/LOC data consists of a Navigation Source, Selected
Course, Backcourse (B/C) ILS Indicator, Lateral Deviation Scale,
Vertical Deviation Scale, and Marker Beacons. See Figure 3-11. An
example of Marker Beacons is shown in Figure 3-13.
The display of GPS data consists of a Navigation Source, Desired
Track (DTK) or Selected Course, TO/FROM indicator, Lateral Deviation
Scale, and Vertical Deviation Scale. See Figure 3-12.
Conguration Options:
• Navigation Mode - VOR/ILS or GPS
• VOR/ILS Annunciator set to VOR/ILS or VOR/LOC, VOR/ILS1 or
VOR/LOC1, VOR/ILS2 or VOR/LOC2, VOR/ILS3 or VOR/LOC3
• GPS Annunciator set to GPS, GPS1, GPS2, or GPS3
• VOR/ILS or GPS Annunciator Color - Green or Magenta
Navigation Source
Located in the lower left corner of the attitude display above the
direction display, the navigation source annunciator shows the
indicator’s current navigation mode.
