Mechanical safety
Mechanical safety
The 5XT rigging system complies with EN 62368-1: 2014 Audio/video, information and communication technology
equipment — Part 1: Safety requirements.
The deployments described in this manual achieve a safety factor of 5.
5XT
Conguration Rigging accessory Maximum / Safe limit
Wall-mounted / ceiling-mounted ETR5 1
Pole-mounted microphone stand 1
Loudspeaker congurations
5XT point source
Deployed as a standalone point source, the 5XT system operates over the nominal bandwidth of the 5XT enclosure.
The [5XT] preset delivers a reference frequency response in short throw applications.
5XT is driven by the LA2Xi / LA4X / LA8 / LA12X amplied controllers.
Enclosure 5XT
Preset [5XT]
Frequency range (-10 dB) 95 Hz - 20 kHz
5XT owner's manual (EN) version 4.0 13
