L-Acoustics 5xt - 5 XT Stage Monitor; Low-Latency Preset

Loudspeaker congurations
5XT stage monitor
Deployed as a stage monitor, the 5XT system operates over the nominal bandwidth of the 5XT enclosure.
The [5XT_MO] preset delivers a reference frequency response in stage monitoring applications.
5XT is driven by the LA2Xi / LA4X / LA8 / LA12X amplied controllers.
Enclosure 5XT
Preset [5XT_MO]
Frequency range (-10 dB) 95 Hz - 20 kHz
Low-latency preset
A low-latency preset is available for the 5XT enclosure used as a monitor ([5XT_MO]). It reduces latency from 3.84ms
down to 1.18ms (LA8) and 0.84ms (LA2Xi / LA4X / LA12X). If the monitor is combined with a subwoofer, a custom
preset must be used.
16 5XT owner's manual (EN) version 4.0
