L-Acoustics 5xt - SpeciCations; 5 Xt

Specications
Specications
5XT specications
Description 2-way passive coaxial enclosure: 5'' LF + 1'' HF diaphragm, amplied by
LA2Xi / LA4X / LA8 / LA12X
Usable bandwidth (-10 dB) 95 Hz - 20 kHz ([5XT])
Maximum SPL
1
121 dB ([5XT])
Nominal directivity (-6 dB) 110° axisymmetric
Transducers LF: 1 × 5" cone driver
HF: 1 × 1" diaphragm compression driver
Acoustical load LF: bass-reex
Nominal impedance 16 Ω
Connectors IN: 1 × 4-point speakON
LINK: 1 × 4-point speakON
IN/LINK: 2 × 2-point screw terminals
Rigging and handling 2 M6 inserts for ETR5
1 × 3/8" insert for microphone stand
Weight (net) 3.5 kg / 7.7 lb
Cabinet premium grade Baltic birch plywood
Front steel with anti-corrosion coating
Finish dark grey brown Pantone 426 C
pure white RAL 9010
custom RAL code on special order
IP IP30 / IP54
2
1
Peak level measured at 1 m under free eld conditions using pink noise with crest factor 4 (preset specied in brackets).
2
IP54 is achieved with the 5XT-SEALPLATE connector sealing plate and a down-tilt angle of 20° and more.
5XT dimensions
165 mm / 6.5 in
5XT owner's manual (EN) version 4.0 39
