Rigging system description
Rigging system description
5XT
5XT features one M6 insert and screw on each side to connect ETR5.
One 3/8" microphone-stand insert is available on the bottom face of 5XT for pole-mounted congurations.
(ETR5)
M6
3/8" insert
M6
(ETR5)
Always put the placeholder screws back in place to avoid leaks.
ETR5
ETR5 is a U-bracket compatible with 5XT.
It can be used to mount one 5XT on the wall or under the ceiling, with site angle adjustment.
When the 5XT is stored, the ETR5 can be used to protect the connectors at the back of the enclosure as illustrated below.
12 5XT owner's manual (EN) version 4.0
