4.2 Connecting ARCS
®
II to LA4X
Maximum of 2 enclosures per LA4X
1 ARCS
®
II can be connected to each pair of output channels on the LA4X (1/2 and 3/4).
Impedance load
8 Ω
 Connect one SP cable (SP.7, SP5, SP10 or SP25) to the OUT1/OUT2 and OUT3/OUT4 connectors of the LA4X.
