L-Acoustics ARCS II User Manual

ARCSII_UM_EN_3.0
w w w . l - a c o u s t i c s . c o m
15
4.4 Connecting SB28 to LA8
Maximum of 4 enclosures per LA8
1 SB28 can be connected to each output channel on the LA8.
CARDIOID configuration with SB28
Connect the reversed subwoofer to OUT 1.
Impedance load
1 enclosure
4 Ω
Option A
 Connect a DO (DO.7, DO10 or DO25) cable to the LA8 PA-COM
®
connector.
 Use the DOSUB-LA8 to split the audio signals into four channels, each one feeding one subwoofer.
