L-Acoustics ARCS II User Manual

ARCS
®
II SYSTEM
user manual
VERSION 3.0
ARCSII_UM_EN_3.0
w w w . l - a c o u s t i c s . c o m
12
4.3 Connecting ARCS
®
II to LA8
Maximum of 4 enclosures per LA8
2 ARCS
®
II can be connected to each pair of output channels on the LA8 (1/2 and 3/4).
Impedance load
1 enclosure
8 Ω
2 enclosures
4 Ω
Option A
 Connect a DO cable (DO.7, DO10 or DO25) to the LA8 PA-COM
®
connector.
 Use a DOFILL-LA8 to split the signal into two channel pairs each one feeding one enclosure.
 Use SP cables to connect additional similar enclosures in parallel with the first ones.
