APPENDIX A PRESET DESCRIPTION
[ARCS II]
The [ARCS II] preset allows for a reference frequency response in medium throw applications.
Loudspeaker elements
Amplifier outputs
Channels
Default parameters
Routing
Gain
Delay
Polarity
Mute
ARCS II
LF
OUT 1
LF
IN A
0 dB
0 ms
+
ON
HF
OUT 2
HF
ON
ARCS II
LF
OUT 3
LF
IN B
0 dB
0 ms
+
ON
HF
OUT 4
HF
ON
[SB28_60]
The [SB28_60] preset provides the SB28 enclosures with an upper frequency limit at 60 Hz, for an optimal frequency
coupling with the ARCS
®
II line source.
Loudspeaker
elements
Amplifier
outputs
Channels
Default parameters
Routing
Gain
Delay
Polarity
Mute
SB28
OUT 1
SB
IN A
0 dB
0 ms
+
ON
SB28
OUT 2
SB
IN A
0 dB
0 ms
+
ON
SB28
OUT 3
SB
IN B
0 dB
0 ms
+
ON
SB28
OUT 4
SB
IN B
0 dB
0 ms
+
ON
[SB28_60_C]
The [SB28_60_C] preset provides the SB28 enclosures with an upper frequency limit at 60 Hz, for an optimal frequency
coupling with the ARCS
®
II line source.
It features optimized delay settings for SB28 arrays in cardioid configuration.
Loudspeaker
elements
Amplifier
outputs
Channels
Default parameters
Routing
Gain
Delay
Polarity
Mute
Reversed SB28
OUT 1
SR*
IN A
0 dB
0 ms
+
ON
SB28
OUT 2
SB
ON
SB28
OUT 3
SB
ON
SB28
OUT 4
SB
ON
* reversed subwoofer
