L-Acoustics K1 User Manual

System components
System components
Loudspeaker enclosures
K1 3-way full-range active WST
®
enclosure
K1-SB K1 system subwoofer 2×15"
K2 3-way full-range active WST enclosure
Kara II 2-way active WST
®
enclosure: 2 × 8" LF + 3" HF diaphragm
KS28 Flyable subwoofer 2 × 18"
Powering and driving system
LA12X Amplied controller 4 × 2600 W / 4 ohms
Refer to the LA12X owner's manual for operating instructions.
Racks
LA-RAK II AVB Touring rack containing three LA12X, LA-POWER II for power distribution, LA-PANEL II for audio
and network distribution, and two LS10 for AVB distribution
Cables
SP cables SpeakON loudspeaker cables (4-point, 4 mm² gauge)
Come in different sizes: SP.7 (0.7 m / 2.3 ft), SP5 (5 m / 16.4 ft), SP10 (10 m / 32.8 ft), and
SP25 (25 m / 82 ft)
SP-Y1 Breakout cable for two passive enclosures (2.5 mm² gauge)
4-point speakON to 2 × 2-point speakON, provided with a CC4FP adapter
DO cables PA-COM loudspeaker cables (8-point, 4 mm² gauge)
Come in different sizes: DO.7 (0.7 m / 2.3 ft), DO.10 (10 m / 32.8 ft), and DO.25 (25 m /
82 ft)
DOSUB-LA8 Breakout cable for four passive enclosures (4 mm² gauge)
8-point PA-COM to 4 × 2-point speakON
DOFILL-LA8 Breakout cable for two 2-way active enclosures (4 mm² gauge)
8-point PA-COM to 2 × 4-point speakON
DO3WFILL Breakout cable for one 2-way active enclosure and two passive enclosures (4 mm² gauge)
8-point PA-COM to 1 × 4-point speakON and 2 × 2-point speakON
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA12X owner's manual for detailed instructions about the whole cabling scheme, including
modulation cables and network.
Rigging elements
K1-BUMP Structure for ying and stacking K1 and K1-SB arrays
K1-DELTA Rigging accessory for rear attachment of 2 motors to K1-BUMP
KARA-DOWNK1 Flying bumper for rigging KARA (II) under K1 or K1-SB
K1-LASERMOUNT K1 laser support plate (compatible TEQSAS / SSE Prosight / Align Array / KSG)
K2-LINK Rigging accessory for rear attachment of K2 below K1
10 K1 owner's manual (EN) version 1.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
