L-Acoustics K1 User Manual

System components
Transportation accessories
K-BUMPFLIGHT Modular ight case for 2 K1-BUMP or 2 K2-BUMP
K1-CHARIOT Chariot for 4 × K1 or 4 × K1-SB
K1-CHARIOTCOV Protective cover for 4 × K1/K1-SB on CHARIOT
K1-PLA Removable front dolly for K1 or K1-SB enclosure
K1-COV Protective cover for K1 enclosure
K1-SBCOV Protective cover for K1-SB enclosure
Software applications
Soundvision 3D acoustical and mechanical modeling software
LA Network Manager Software for remote control and monitoring of amplied controllers
Refer to the Soundvision help.
Refer to the LA Network Manager help.
System component illustrations
Cables
0.7 m / 5 m / 10 m / 25 m
2.3 ft / 16.4 ft / 32.8 ft / 82 ft
CH(1)
CH(2)
1 m / 3.3 ft
SP cables SP-Y1
0.7 m / 10 m / 25 m
2.3 ft / 32.8 ft / 82 ft
SPK1
SPK2
SPK3
SPK4
5 m / 16.4 ft
DO cables DOSUB-LA8
2W CH(A)
2W CH(B)
3.5 m / 11.5 ft
2WAY
SUB1
SUB2
3.5 m / 11.5 ft
DOFILL-LA8 DO3WFILL
K1 owner's manual (EN) version 1.0 11

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
