Electro-acoustical description
Connectors
IN
LINK
K1
2 x 8-point PA-COM
IN
LINK
K2
2 x 8-point PA-COM
Internal pinout for L-Acoustics 3-way active enclosures
PA-COM points A/B C/D E/F G/H
Transducer connectors left LF right LF MF HF
16 K1 owner's manual (EN) version 1.0
