L-Acoustics K1 User Manual

Connection to LA amplied controllers
Cabling scheme for Kara II
Four-channel CA-COM output
DO
SP
DOFILL-LA8
2W CH(A)
2W CH(B)
DO
SP
DO3WFILL
2WAY
SUB2
SUB1
Two-channel speakON output
SP
SP
1+/1-
2+/2-
106 K1 owner's manual (EN) version 1.0

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
