L-Acoustics MTD Series - Table 14: Output Power Ratings and MLS Switch Settings for L-ACOUSTICS Laa Amplifiers

L-ACOUSTICS MTD Manual V1.2 11/30/2004 22
L-ACOUSTICS LA 15a POWER MATRIX L-ACOUSTICS LA 17a POWER MATRIX
MLS SWITCH SETTING MLS SWITCH SETTING
LOAD CONFIGURATION -3 dB 0 dB LOAD CONFIGURATION -3 dB 0 dB
16 ohms Quad (4 channel) 95 200 16 ohms Stereo (2 channel) 110 215
8 ohms Quad (4 channel) 200 370 8 ohms Stereo (2 channel) 220 430
4 ohms Quad (4 channel) 380 600 4 ohms Stereo (2 channel) 430 840
2.7 ohms Quad (4 channel) 460 2.7 ohms Stereo (2 channel) 720 1080
2 ohms Quad (4 channel) 500 2 ohms Stereo (2 channel) 870 1200
L-ACOUSTICS LA 24a POWER MATRI
X
L-ACOUSTICS LA 48a POWER MATRIX
MLS SWITCH SETTING MLS SWITCH SETTING
LOAD CONFIGURATION -5 dB -4 dB -2 dB 0 dB LOAD CONFIGURATION -5 dB -4 dB -2 dB 0 dB
16 ohms Stereo (2 channel) 160 200 340 520 16 ohms Stereo (2 channel) 220 260 410 650
8 ohms Stereo (2 channel) 300 400 700 1100 8 ohms Stereo (2 channel) 430 520 820 1300
4 ohms Stereo (2 channel) 600 750 1300 1500 4 ohms Stereo (2 channel) 830 1000 1600 2300
2.7 ohms Stereo (2 channel) 1000 1180 1465 1635 2.7 ohms Stereo (2 channel) 1380 1665 2130 2700
2 ohms Stereo (2 channel) 1200 1400 1550 1700 2 ohms Stereo (2 channel) 1660 2000 2400 2900
Table 14: Output Power Ratings and MLS Switch Settings for L-ACOUSTICS LAa Amplifiers
