COMPONENT MAINTENANCE MANUAL
AVIATION PRODUCTS
Model FA5000
Rev. 02 Page 120
July 21/17
Testing & Fault Isolation
23–70−30
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
D. READ OUT CENTER/7 (ROC/7) − Autotest Descriptions
The following provides detailed descriptions of the test performed during the autotest
function.
(1) Power Test
Test Prompts the user for DC power usage as in the following DC example:
Please remove the front panel cable from the recorder now and click ”OK”.
Please enter the DC power consumption (in amps or watts)
Please enter the DC power consumption (in amps or watts)
Please connect the recorder front panel cable and press the ”OK” button.
Example report message(s):
08:02:23 PASSED Power(DC) (Expected <= 11 watts) Results = (12.375 watts
– 2.2 watts) = 10.175 watts
(2) Fault Log
Displays the current recorder fault log for user review and prompts the user:
“Clear fault log?”
Select “yes” when testing the FA2100 recorder and the full fault log is NOT to be
written to the test report.
Continue CVDR Tests?
Select “yes” to continue or “no” to stop testing.
Example report message(s)
08:02:32 PASSED Fault History
