COMPONENT MAINTENANCE MANUAL
AVIATION PRODUCTS
Model FA5000
Fits and Clearances
23–70–30
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
Rev. 02 Page 801
July 21/17
FITS AND CLEARANCES
1. GENERAL
This section provides the Model FA5000 recorder’s specifications and outline and dimen-
sions. Since the recorder uses solid−state memory recording technology, there are no in-
ternal fits and clearances or tension values normally associated with older technology
electromechanical tape recorder units.
The information contained herein is also in the Description/Operation section of this CMM
and is presented here for the purpose of quick reference.
2. SYSTEM SPECIFICATIONS
The Model FA5000 meets the performance requirements of ED−112, chapter 2, and Part
I, while conforming to the input interface required in ARINC 757/757A.
3. Physical Characteristics
The Model FA5000 fits within the envelope of an ARINC 404A 1/2-ATR short case. (Re-
fer to Figure 801) for outline and dimension illustration.
Characteristic Measurement
Height 6.48 inches nominal
Width 5.02 inches nominal (front panel)
12.6 inches nominal (behind front panel)
Depth 13.1 inches nominal (including hold-down hooks)
Weight (ULB installed)
10.4 pounds for models
5003−5000−00, 5003−5001−50. 5013−5001−50
8.6 pounds for 5003−5000−01
10.5 pounds for 5013−5000−30
Markings International Orange (FED–STD–595 Color No. 12197),
Reflective Striping on Crash−Survivable Memory Unit,
English and French Markings
Main (Rear) Connector 57-Pin Connector Compatible with ARINC 757 or 757A,
P/N: 063E1072–00
(Cannon Part Number DPXB–36571–59)
Main (Rear) Mating
Connectors
Crimp: L3AP P/N: 063-98-01474
(Cannon Part Number DPXBMA–57–33S–0001)
Solder: Part Number 9300–435
(Cannon Part Number DPXB–57–33S–0001)
Ground Support
Equipment Connector: (J2)
Ethernet RJ45
