COMPONENT MAINTENANCE MANUAL
AVIATION PRODUCTS
Model FA5000
Table of Contents
23–70–30
Rev. 02 Page xxii
Use or disclosure of information on this sheet is subject to
the restrictions on the cover page of this document.
July 21/17
TABLE OF CONTENTS
DISASSEMBLY
SUBJECT/DESCRIPTION PAGE
1. GENERAL 301.................................................................
2. RECORDER INDEPENDENT POWER SUPPLY (RIPS) MODULE 301................
A. Remove RIPS Module 301................................................
B. Condition RIPS Module After Expired Shelf Life (One Year in Storage) 302......
3. STORAGE INSTRUCTIONS 303.................................................
A. Storage of the RIPS Module in Original Container 303........................
B. Storage of RIPS Without Original Container 303.............................
4. MODEL FA5000 DISASSEMBLY INSTRUCTIONS 304..............................
A. Underwater Locator Beacon Removal
(See IPL Figure 1, Item 150) 304..........................................
B. Crash Survivable Memory Unit (CSMU) Removal
(See Figure 302 or IPL Figure 1, Item 120) 304..............................
C. Rear Cover Removal
(See Figure 304 or IPL Figure 1, Item 10) 306...............................
D. Aircraft Interface (AI) PWA Removal
(See Figure 304 or IPL Figure 1, Item 25) 307...............................
CLEANING
1. GENERAL 401.................................................................
2. MATERIALS REQUIRED 401....................................................
3. CLEANING PROCEDURES 401.................................................
A. Printed Wiring Assembly Cleaning 402.....................................
B. Connector Cleaning 402..................................................
C. Underwater Locator Beacon Cleaning 402..................................
