23
SERVICING WARNING WORK SAFELY
Where necessary disconnect from electricity and gas before starting.
Check range is safe when you have finished.
18 To Change the Oven Outer Door Panel or Door Trim Parts
The door outer panel and all the trim parts are
available as separate parts so that individual parts
can be changed.
Door is very heavy - take care.
Unscrew the door handle and remove the handle and
door trim handle disk..
Open the oven door. Remove the hexagon headed
screws ‘A’ and ‘B’ (two each side) from the door.
Carefully lift of the door outer.
Place the outer panel on a clean fl at surface.
As can be seen in the photograph the door trim
handle plate is held in place by screws on the inside.
Studs and nuts hold the other trims.
Replace the damaged parts and re-assemble in
reverse order.
