La Cornue CornuFe - To Remove the Cooktop

15
SERVICING  WARNING  WORK SAFELY
Where necessary disconnect from electricity and gas before starting.
Check range is safe when you have finished.
3 To Remove the Cooktop
Move the range away from the wall - see ‘How To Move the Range for Servicing’.
Remove cooktop grates and burner heads.
Undo the large brass nuts and remove the brass
venturis and washers.
Lift up the front of the cooktop top and prop it up. Disconnect the ignition leads from the electrodes and remove
the burner bezels. Lift the cooktop clear of the range.
Replace in reverse order.
