Projection: Intensity, Rotation Backlight
Projection Intensity:
• Power cord is required for constant projection.
• Press and release the SNOOZE/LIGHT button to adjust the
projection HI-LOW-OFF.
Note: This will adjust the backlight at the same time.
• If operating on battery power, press the SNOOZE/LIGHT
button to activate the projection for 10 seconds.
Projection Rotation:
• Press the PROJECTION button to rotate
the projection image 90 degrees.
• Press the PROJECTION button again to
rotate another 90 degrees.
Projection: Modes Time, Temperature
1. Hold, then release the PROJECTION button to switch
projection modes.
2. Watch the projection image to view the changes.
Projection Modes:
• Time and Outdoor Temperature: alternates every 5 seconds
(default)
• Time only
• Outdoor Temperature only
• Power cord is required for constant backlight.
• Press and release the SNOOZE/LIGHT button to adjust the
backlight HI-LOW-OFF.
Note: This will adjust the projection at the same time.
• If operating on battery power, press the SNOOZE/LIGHT
button to activate the backlight for 10 seconds.
There is a 1 Amp USB charging port on the back of your clock.
The included power adapter must be in use to charge a
device with your own cable.
• Connect your external device’s USB charging cable (not
included) to the USB charging port.
• Charging times will vary.
• USB Power Output: 1A maximum current.
• Charge 1A devices or devices that are self-regulating.
USB Charging Port
• The UP and DOWN arrows indicate changes in temperature
and humidity over the past three hours.
• They update every 30 minutes and compare data from
three hours prior.
Temperature: arrow changes every 2°F (1°C).
Temperature Trend Arrows
Page | 5 www.lacrossetechnology.com/support 616-146v3 616-146v3 www.lacrossetechnology.com/support Page | 6
