Laars NTV1000 - Parts Illustrations; Machine Frame Diagrams

LAARS Heating Systems
Page 120
Key
No.
Part No. -
1000
Part No. -
1700
Description
82 R2073812 R2073812 GASKET, D-SHAPE, RUBBER,
R2073903 R2073903 GASKET, STRIP, FOAM, ADHESIVE, 3/8 X 1/8
83 10J1231 17J1231 Cross brace, Front HX, BASE
84 R10J1221 R17J1221 PANEL, SIDE, ASSY WITH GASKE TS
85 R2074405 R2074405 GASKET, CLOSED CELL, .75” X .06” X 47”
R2073909 R2073909 GASKET, STRIP, FOAM, ADHESIVE, 3/8 X 1/8 X 53” LG
86 R10J1234 10J1234 TOP CENTER SUPPORT
R2073903 R2073903 GASKET STRIP, FOAM 3/8”X1/8”X5.75”L
87 R10J1245 R10J1245 BRACKET, SEALING, BEZEL
R2074503 R2074503 EDGE GRIP RUBBER SEAL 3/64 -9/64 X 26.625 LG
F2022100 F2022100 SCREW, SELF TAPPING, #8 X 3/8” LG. TYPE A, HEX HEAD
88 R10J1219 R17J1219 TOP, CASE ASSY
89 R2073812 R2073815 GASKET, D-SHAPE, RUBBER, 14’
R2074405 R2074405 GASKET, CLOSED CELL, .75” X .06” X 26.75”
90 A0063600 A0063600 PRESSURE RELIEF VALVE (75PSI)
A2114802 A2114802 PRESSURE RELIEF VALVE (125PSI)
91 S2117900 O-RING, 1 7/16” OD X 1/16, BUNA-N
92 A2116700 VENTURI. GAS/AIR MIXING
93 RS2105200 O-RING, 4MM THICK X 110MM ID
94 RA2113100 BLOWER, COMBUSTION AIR
100 S2116800 GASKET, FAN FLANGE
101 P0026800 PLUG, PIPE, BRASS, 1/4” NPT
P2080300 PLUG, PIPE, STAINLESS STEEL, 1/4” NPT
102 P0071500 PLUG, 3/4” STEEL
P2080200 PLUG, 3/4” STAINLESS STEEL
103 RE2319900 RE2319900 SENSOR, TEMPERATURE, WATER, DUPLEX
104 R1-592 R1-592 COIN VENT VALVE
105 F2029100 TIE, CABLE, 14-3/4 LONG X 0.31” WIDE, HEAT STABILIZED
106 S2117801 HEAT EXCHANGER, GIANNONI TRIO
107 10J4047 CLIP, QUICK DISCONNECT
108 S2116900 O-RING, 61mm x 53mm x 4mm
109 E2339400 E2339400 THERMISTOR, NTC, 1/8” NPT, STAINLESS STEEL WELL
110 E2340000 E2340000 SENSOR, TEMPERATURE, STACK, 1/4” NPT
111 P2079200 P2079200 PLUG, PIPE, 1” NPT, CI (NTH)
P0001100 P0001100 BUSHING 1” NPT X 3/4” NPT BLK (NTH CSD-1)
P2080400 P2080400 PLUG, PIPE, 1” NPT, STAINLESS STEEL (NTV)
P2081700 P2081700 BUSHING 1” NPT X 3/4” NPT STAINLESS STEEL (NTV CSD-1)
112 P2079000 P2079000 VALVE, CHECK, 1/2” X 1/4 BSPP
113 RP2078900 RP2078900 WELL, IMMERSION, 1/2” NPT, 2” LONG W/ CLIP
114 P2079100 P2079100 CLIP, LOCKING, IMMERSION WELL
115 P2016000 P2016000 PLUG, 1/2” STEEL (NTH)
P2080500 P2080500 PLUG, 1/2”, STAINLESS STEEL (NTV)
116 10J4040 PIPE, WATER OUTLET ASSY (NTH)
10J4060 PIPE, WATER OUTLET STAINLESS STEEL, ASSY (NTV)
