NeoTherm LC Boilers and Water Heaters
Page 31
Fig. 20 - Electronics Panel Layout
TB5
TB2
TB1
Primary controller
(upper burner)
Secondary controller
(lower burner)
TB7
TB6
TB4
TB3
TB10
TB9
