= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=V=ENTF=
=
Position Partnumber Description Comment Side
R217 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R218 10K.7W1% Resistor Metal Film 10K.7W1% Top
R222 100R.7W1% Resistor Metal Film 100R.7W1% Top
R223 22K.25W5% Resistor Carbon Film 22K.25W5% Top
R224 100R.7W1% Resistor Metal Film 100R.7W1% Top
R225 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R226 6K8.7W1% Resistor Metal Film 6K8.7W1% Top
R227 - Not used Top
R228 6K8.7W1% Resistor Metal Film 6K8.7W1% Top
R229 30K.7W1% Resistor Metal Film 30K.7W1% Top
R230 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R231 Variant dependent, see separate list Top
R232 Variant dependent, see separate list Top
R233 Variant dependent, see separate list Top
R234 Variant dependent, see separate list Top
R235 Variant dependent, see separate list Top
R236 Variant dependent, see separate list Top
R237 Variant dependent, see separate list Top
R238 Variant dependent, see separate list Top
R239 Variant dependent, see separate list Top
R240 Variant dependent, see separate list Top
R241 Variant dependent, see separate list Top
R242 Variant dependent, see separate list Top
R243 Variant dependent, see separate list Top
R244 Variant dependent, see separate list Top
R245 Variant dependent, see separate list Top
R246 Variant dependent, see separate list Top
R247 Variant dependent, see separate list Top
R248 Variant dependent, see separate list Top
R249 Variant dependent, see separate list Top
R250 Variant dependent, see separate list Top
R251 - Not used Top
R252 10K.7W1% Resistor Metal Film 10K.7W1% Top
R253 10K.7W1% Resistor Metal Film 10K.7W1% Top
R254 10K.7W1% Resistor Metal Film 10K.7W1% Top
R255 10K.7W1% Resistor Metal Film 10K.7W1% Top
R256 2K.7W1% Resistor Metal Film 2K.7W1% Top
R257 4K.7W1% Resistor Metal Film 4K.7W1% Top
R258 4K.7W1% Resistor Metal Film 4K.7W1% Top
R259 2K.7W1% Resistor Metal Film 2K.7W1% Top
R261 47K.7W1% Resistor Metal Film 47K.7W1% Top
R262 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R263 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R267 100R.7W1% Resistor Metal Film 100R.7W1% Top
R268 22K.25W5% Resistor Carbon Film 22K.25W5% Top
R269 100R.7W1% Resistor Metal Film 100R.7W1% Top
R270 Variant dependent, see separate list Top
R271 Variant dependent, see separate list Top
R272 - Not used Top
R273 Variant dependent, see separate list Top
R274 Variant dependent, see separate list Top
R275 Variant dependent, see separate list Top
R276 Variant dependent, see separate list Top
R277 Variant dependent, see separate list Top
R278 Variant dependent, see separate list Top

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
