= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NM=ENTF=
=
Position Partnumber Description Comment Side
R279 Variant dependent, see separate list Top
R280 Variant dependent, see separate list Top
R281 Variant dependent, see separate list Top
R282 Variant dependent, see separate list Top
R283 Variant dependent, see separate list Top
R284 Variant dependent, see separate list Top
R285 Variant dependent, see separate list Top
R286 Variant dependent, see separate list Top
R287 Variant dependent, see separate list Top
R288 Variant dependent, see separate list Top
R289 Variant dependent, see separate list Top
R290 Variant dependent, see separate list Top
R291 Variant dependent, see separate list Top
R292 Variant dependent, see separate list Top
R293 Variant dependent, see separate list Top
R294 Variant dependent, see separate list Top
R295 Variant dependent, see separate list Top
R296 - Not used Top
R297 Variant dependent, see separate list Top
R298 Variant dependent, see separate list Top
R299 Variant dependent, see separate list Top
R300 Variant dependent, see separate list Top
R301 Variant dependent, see separate list Top
R302 Variant dependent, see separate list Top
R303 Variant dependent, see separate list Top
R304 Variant dependent, see separate list Top
R306 Variant dependent, see separate list Top
R307 Variant dependent, see separate list Top
R308 Variant dependent, see separate list Top
R312 Variant dependent, see separate list Top
R313 Variant dependent, see separate list Top
R314 Variant dependent, see separate list Top
R500 100R.7W1% Resistor Metal Film 100R.7W1% Top
R501 100R.7W1% Resistor Metal Film 100R.7W1% Top
R502 2K2.25W5% Resistor Carbon Film 2K2.25W5% Top
R503 10K.7W1% Resistor Metal Film 10K.7W1% Top
R504 10K.7W1% Resistor Metal Film 10K.7W1% Top
R505 33R.25W5% Resistor Carbon Film 33R.25W5% Top
R506 33R.25W5% Resistor Carbon Film 33R.25W5% Top
R507 100R.7W1% Resistor Metal Film 100R.7W1% Top
R508 Variant dependent, see separate list Top
R510 19K6.7W1% Resistor Metal Film 19K6.7W1% Top
R511 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
R512 220R.7W1% Resistor Metal Film 220R.7W1% Top
R600 - Not used Top
RE1 PCDPCO1A24V Relay PCB double pole change over 1A 24V Top
RE2 PCDPCO1A24V Relay PCB double pole change over 1A 24V Top
RE3 Variant dependent, see separate list Top
S1 DI1-1_EPC Switch DIL single pole double through EPCOS C42315A1347-
A212
Top
S2 Variant dependent, see separate list Top
S3 DI1-1_EPC Switch DIL single pole double through EPCOS C42315A1347-
A212
Top
S4 DI1-1_EPC Switch DIL single pole double through EPCOS C42315A1347-
A212
Top
S5 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
