Page #12 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NN=ENTF=
=
Position Partnumber Description Comment Side
S6 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
S7 Variant dependent, see separate list Top
S8 RDHEX Switch rotary DIL HEX Top
S9 RDHEX Switch rotary DIL HEX Top
S10 RDHEX Switch rotary DIL HEX Top
S11 RDHEX Switch rotary DIL HEX Top
S12 Variant dependent, see separate list Top
S13 Variant dependent, see separate list Top
S14 Variant dependent, see separate list Top
S15 Variant dependent, see separate list Top
S16 Variant dependent, see separate list Top
S201 DI1-1_EPC Switch DIL single pole double through EPCOS C42315A1347-
A212
Top
S202 Variant dependent, see separate list Top
S203 DI1-1_EPC Switch DIL single pole double through EPCOS C42315A1347-
A212
Top
S205 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
S206 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
S207 Variant dependent, see separate list Top
S208 RDHEX Switch rotary DIL HEX Top
S209 RDHEX Switch rotary DIL HEX Top
S210 RDHEX Switch rotary DIL HEX Top
S211 RDHEX Switch rotary DIL HEX Top
S212 Variant dependent, see separate list Top
S213 Variant dependent, see separate list Top
S214 Variant dependent, see separate list Top
S215 Variant dependent, see separate list Top
S216 Variant dependent, see separate list Top
S501 RK2-0-10A15x21 Switch Rocker Double Pole Single Trough on - off 10A
15x21mm
Top
T1 - Not used Top
T3 6W4x7.5V23x44x53 Transformer PCB 6W 4x7.5V 23x44x53mm Top
T201 - Not used Top
U1 NE5532 IC Operational amplifier NE5532 Top
U2 LF353 IC Operational amplifier LF353 Top
U3 LF353 IC Operational amplifier LF353 Top
U4 Variant dependent, see separate list Top
U5 LF353 IC Operational amplifier LF353 Top
U6 LF353 IC Operational amplifier LF353 Top
U7 LF353 IC Operational amplifier LF353 Top
U8 Variant dependent, see separate list Top
U9 Variant dependent, see separate list Top
U10 Variant dependent, see separate list Top
U11 NE5532 IC Operational amplifier NE5532 Top
U12 NE5532 IC Operational amplifier NE5532 Top
U13 Variant dependent, see separate list Top
U201 NE5532 IC Operational amplifier NE5532 Top
U205 LF353 IC Operational amplifier LF353 Top
U206 LF353 IC Operational amplifier LF353 Top
U207 LF353 IC Operational amplifier LF353 Top
U208 Variant dependent, see separate list Top
U209 Variant dependent, see separate list Top
U210 Variant dependent, see separate list Top
U500 UA741 IC Operational amplifier UA741 Top

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
