= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NT=ENTF=
=
pé~êÉé~êí=äáëí=Ñçê=^`kJ`=
Mecanical parts
Partnumber Description
TCACNC Top cover
BCACNC Bottom cover
FP-ACN2C Front panel ACN 2C
FP-ACN2S Front panel ACN 2S
FP-ACN3C Front panel ACN 3C
RP-ACN2C Rear panel ACN 2C
RP-ACN2S Rear panel ACN 2S
RP-ACN3C Rear panel ACN 3C
SPACNC Side panel
KNBD18.5_TAI Level potentiometer knob
KNB5x5GRY Mute switch knob
Screws
Partnumber Description
MK6S3x10SV Hexagon socket screw, button head, M3x10, black
RTS-HST2.9x9.5SV Self tapping screw, pan head, torx, 2.9x9.5mm, black
RXS-HST2.9x6.5SV Self tapping screw, pan head, phillips, 2.9x6.5mm, black
RXS-HST3.5x13SV Self tapping screw, pan head, phillips, 3.5x13mm, black

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
