= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NS=ENTF=
=
100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm
100R.7W1% Resistor Metal Film 100R.7W1%
10K.7W1% Resistor Metal Film 10K.7W1%
12K.7W1% Resistor Metal Film 12K.7W1%
150p500VK20005%5 Capacitor ceramic 150p 500V K2000 5% 5mm
15K.7W1% Resistor Metal Film 15K.7W1%
19K6.7W1% Resistor Metal Film 19K6.7W1%
1K.7W1% Resistor Metal Film 1K.7W1%
1N4148 Diode signal 1N4148
220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm
22K.25W5% Resistor Carbon Film 22K.25W5%
27R.7W1% Resistor Metal Film 27R.7W1%
2K.7W1% Resistor Metal Film 2K.7W1%
30K.7W1% Resistor Metal Film 30K.7W1%
330n63VMMK5 Capacitor polyester 330n 63V MMK 5mm
470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm
47K.7W1% Resistor Metal Film 47K.7W1%
47p100VNP05%5 Capacitor ceramic 47p 100V NP0 5% 5mm
47u25V Capacitor electrolytic 47u 25V 5mm
4K.7W1% Resistor Metal Film 4K.7W1%
4K7.7W1% Resistor Metal Film 4K7.7W1%
60K4.7W1% Resistor Metal Film 60K4.7W1%
680p400VK20005%5 Capacitor ceramic 680p 400V K2000 5% 5mm
68n63VMMK5 Capacitor polyester 68n 63V MMK 5mm
6K8.7W1% Resistor Metal Film 6K8.7W1%
6n8250VMMK5 Capacitor polyester 6n8 250V MMK 5mm
7K5.7W1% Resistor Metal Film 7K5.7W1%
7K87.7W1% Resistor Metal Film 7K87.7W1%
DI1-1_EPC Switch DIL single pole double through EPCOS C42315A1347-A212
LF353 IC Operational amplifier LF353
NC3MA-H_NEU Connector XLR 3pole male 90dg NEUTRIK NC3MA-H
NE5532 IC Operational amplifier NE5532
PCDPCO1A24V Relay PCB double pole change over 1A 24V
R03M.6 Resistor jumper 0R 3modules D.6mm
R04M.6 Resistor jumper 0R 4modules D.6mm
RDHEX Switch rotary DIL HEX
SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A
VR10KLIN2_TOK Potentiometer 10K LIN 2step TOKOS B103 TP96N01 RY5194A
VR47KLY2X3M Trimpotentiometer 47K lying 2x3modules

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
