Page #16 background imageLoading...
Page #16 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NR=ENTF=
=
Position ACNC-2C ACNC-2S ACNC-3C
R288 - - 4K.7W1%
R289 - - 2K.7W1%
R290 - - 1K.7W1%
R291 - - 4K7.7W1%
R292 - - 7K87.7W1%
R293 - - 4K.7W1%
R294 - - 2K.7W1%
R295 - - 1K.7W1%
R297 - - 10K.7W1%
R298 - - 10K.7W1%
R299 - - 10K.7W1%
R300 - - 10K.7W1%
R301 - - 2K.7W1%
R302 - - 4K.7W1%
R303 - - 4K.7W1%
R304 - - 2K.7W1%
R306 - - 47K.7W1%
R307 - - 4K7.7W1%
R308 - - 4K7.7W1%
R312 - - 100R.7W1%
R313 - - 22K.25W5%
R314 - - 100R.7W1%
R508 27R.7W1% 27R.7W1% R04M.6
RE3 - - PCDPCO1A24V
S2 R03M.6 R03M.6 DI1-1_EPC
S7 - - SPPJ32F29A_ALP
S12 - - RDHEX
S13 - - RDHEX
S14 - - RDHEX
S15 - - RDHEX
S16 R03M.6 R03M.6 DI1-1_EPC
S202 R03M.6 R03M.6 DI1-1_EPC
S207 - - SPPJ32F29A_ALP
S212 - - RDHEX
S213 - - RDHEX
S214 - - RDHEX
S215 - - RDHEX
S216 R03M.6 R03M.6 DI1-1_EPC
U4 - - LF353
U8 - - LF353
U9 - - LF353
U10 - - LF353
U13 - - NE5532
U208 - - LF353
U209 - - LF353
U210 - - LF353
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
