= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NQ=ENTF=
=
Position ACNC-2C ACNC-2S ACNC-3C
R98 - - 10K.7W1%
R99 - - 10K.7W1%
R100 - - 10K.7W1%
R101 - - 2K.7W1%
R102 - - 4K.7W1%
R103 - - 4K.7W1%
R104 - - 2K.7W1%
R106 - - 47K.7W1%
R107 - - 4K7.7W1%
R108 - - 4K7.7W1%
R112 - - 100R.7W1%
R113 - - 22K.25W5%
R114 - - 100R.7W1%
R231 10K.7W1% 12K.7W1% 4K7.7W1%
R232 7K87.7W1% 60K4.7W1% 7K87.7W1%
R233 4K.7W1% 30K.7W1% 4K.7W1%
R234 2K.7W1% 15K.7W1% 2K.7W1%
R235 1K.7W1% 7K5.7W1% 1K.7W1%
R236 10K.7W1% 12K.7W1% 4K7.7W1%
R237 7K87.7W1% 60K4.7W1% 7K87.7W1%
R238 4K.7W1% 30K.7W1% 4K.7W1%
R239 2K.7W1% 15K.7W1% 2K.7W1%
R240 1K.7W1% 7K5.7W1% 1K.7W1%
R241 10K.7W1% 12K.7W1% 4K7.7W1%
R242 7K87.7W1% 60K4.7W1% 7K87.7W1%
R243 4K.7W1% 30K.7W1% 4K.7W1%
R244 2K.7W1% 15K.7W1% 2K.7W1%
R245 1K.7W1% 7K5.7W1% 1K.7W1%
R246 10K.7W1% 12K.7W1% 4K7.7W1%
R247 7K87.7W1% 60K4.7W1% 7K87.7W1%
R248 4K.7W1% 30K.7W1% 4K.7W1%
R249 2K.7W1% 15K.7W1% 2K.7W1%
R250 1K.7W1% 7K5.7W1% 1K.7W1%
R270 - - 19K6.7W1%
R271 - - 6K8.7W1%
R273 - - 6K8.7W1%
R274 - - 30K.7W1%
R275 - - 19K6.7W1%
R276 - - 4K7.7W1%
R277 - - 7K87.7W1%
R278 - - 4K.7W1%
R279 - - 2K.7W1%
R280 - - 1K.7W1%
R281 - - 4K7.7W1%
R282 - - 7K87.7W1%
R283 - - 4K.7W1%
R284 - - 2K.7W1%
R285 - - 1K.7W1%
R286 - - 4K7.7W1%
R287 - - 7K87.7W1%
