Page #14 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=NP=ENTF=
=
Position ACNC-2C ACNC-2S ACNC-3C
P5 - - VR10KLIN2_TOK
P6 - - VR47KLY2X3M
P205 - - VR10KLIN2_TOK
P206 - - VR47KLY2X3M
R31 10K.7W1% 12K.7W1% 4K7.7W1%
R32 7K87.7W1% 60K4.7W1% 7K87.7W1%
R33 4K.7W1% 30K.7W1% 4K.7W1%
R34 2K.7W1% 15K.7W1% 2K.7W1%
R35 1K.7W1% 7K5.7W1% 1K.7W1%
R36 10K.7W1% 12K.7W1% 4K7.7W1%
R37 7K87.7W1% 60K4.7W1% 7K87.7W1%
R38 4K.7W1% 30K.7W1% 4K.7W1%
R39 2K.7W1% 15K.7W1% 2K.7W1%
R40 1K.7W1% 7K5.7W1% 1K.7W1%
R41 10K.7W1% 12K.7W1% 4K7.7W1%
R42 7K87.7W1% 60K4.7W1% 7K87.7W1%
R43 4K.7W1% 30K.7W1% 4K.7W1%
R44 2K.7W1% 15K.7W1% 2K.7W1%
R45 1K.7W1% 7K5.7W1% 1K.7W1%
R46 10K.7W1% 12K.7W1% 4K7.7W1%
R47 7K87.7W1% 60K4.7W1% 7K87.7W1%
R48 4K.7W1% 30K.7W1% 4K.7W1%
R49 2K.7W1% 15K.7W1% 2K.7W1%
R50 1K.7W1% 7K5.7W1% 1K.7W1%
R70 - - 19K6.7W1%
R71 - - 6K8.7W1%
R73 - - 6K8.7W1%
R74 - - 30K.7W1%
R75 - - 19K6.7W1%
R76 - - 4K7.7W1%
R77 - - 7K87.7W1%
R78 - - 4K.7W1%
R79 - - 2K.7W1%
R80 - - 1K.7W1%
R81 - - 4K7.7W1%
R82 - - 7K87.7W1%
R83 - - 4K.7W1%
R84 - - 2K.7W1%
R85 - - 1K.7W1%
R86 - - 4K7.7W1%
R87 - - 7K87.7W1%
R88 - - 4K.7W1%
R89 - - 2K.7W1%
R90 - - 1K.7W1%
R91 - - 4K7.7W1%
R92 - - 7K87.7W1%
R93 - - 4K.7W1%
R94 - - 2K.7W1%
R95 - - 1K.7W1%
R97 - - 10K.7W1%

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
