Page #5 background imageLoading...
Page #5 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=Q=ENTF=
=
`çãéçåÉåí=äáëí=Ñçê=^`kJ`=J=êÉî=MQ^=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C2 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C3A 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C3B 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C4 R02M.6 Resistor jumper 0R 2modules D.6mm Top
C5 220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm Top
C6 220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm Top
C7 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C8 68n63VMMK5 Capacitor polyester 68n 63V MMK 5mm Top
C9 47u25V Capacitor electrolytic 47u 25V 5mm Top
C10A Variant dependent, see separate list Top
C10B Variant dependent, see separate list Top
C11A Variant dependent, see separate list Top
C11B Variant dependent, see separate list Top
C12A Variant dependent, see separate list Top
C12B Variant dependent, see separate list Top
C13A Variant dependent, see separate list Top
C13B Variant dependent, see separate list Top
C14 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C15 Variant dependent, see separate list Top
C16 47u25V Capacitor electrolytic 47u 25V 5mm Top
C18A Variant dependent, see separate list Top
C18B - Not used Top
C19A Variant dependent, see separate list Top
C19B - Not used Top
C20A Variant dependent, see separate list Top
C20B - Not used Top
C21A Variant dependent, see separate list Top
C21B - Not used Top
C22 Variant dependent, see separate list Top
C23 Variant dependent, see separate list Top
C24 Variant dependent, see separate list Top
C25 47u25V Capacitor electrolytic 47u 25V 5mm Top
C26 47p100VNP05%5 Capacitor ceramic 47p 100V NP0 5% 5mm Top
C27 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C28 Variant dependent, see separate list Top
C29 47p100VNP05%5 Capacitor ceramic 47p 100V NP0 5% 5mm Top
C30 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C31 Variant dependent, see separate list Top
C32 Variant dependent, see separate list Top
C33 Variant dependent, see separate list Top
C34 - Not used Top
C35 - Not used Top
C36 150p500VK20005%5 Capacitor ceramic 150p 500V K2000 5% 5mm Top
C37 150p500VK20005%5 Capacitor ceramic 150p 500V K2000 5% 5mm Top
C38 Variant dependent, see separate list Top
C201 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C202 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C203A 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C203B 4u750V Capacitor electrolytic 4u7 50V 5mm Top
C204 R02M.6 Resistor jumper 0R 2modules D.6mm Top
C205 220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm Top

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
