Page #6 background image
= pÉêîáÅÉ=j~åì~ä=^`k=O`I=OpI=P`= m~ÖÉ=R=ENTF=
=
Position Partnumber Description Comment Side
C206 220n63VMMK5 Capacitor polyester 220n 63V MMK 5mm Top
C207 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C208 68n63VMMK5 Capacitor polyester 68n 63V MMK 5mm Top
C209 47u25V Capacitor electrolytic 47u 25V 5mm Top
C210A Variant dependent, see separate list Top
C210B Variant dependent, see separate list Top
C211A Variant dependent, see separate list Top
C211B Variant dependent, see separate list Top
C212A Variant dependent, see separate list Top
C212B Variant dependent, see separate list Top
C213A Variant dependent, see separate list Top
C213B Variant dependent, see separate list Top
C214 100p200VNP05%5 Capacitor ceramic 100p 200V NP0 5% 5mm Top
C215 Variant dependent, see separate list Top
C216 47u25V Capacitor electrolytic 47u 25V 5mm Top
C218A Variant dependent, see separate list Top
C218B - Not used Top
C219A Variant dependent, see separate list Top
C219B - Not used Top
C220A Variant dependent, see separate list Top
C220B - Not used Top
C221A Variant dependent, see separate list Top
C221B - Not used Top
C222 Variant dependent, see separate list Top
C223 Variant dependent, see separate list Top
C224 Variant dependent, see separate list Top
C225 47u25V Capacitor electrolytic 47u 25V 5mm Top
C226 47p100VNP05%5 Capacitor ceramic 47p 100V NP0 5% 5mm Top
C227 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C228 Variant dependent, see separate list Top
C229 47p100VNP05%5 Capacitor ceramic 47p 100V NP0 5% 5mm Top
C230 470p200VNP05%5 Capacitor ceramic 470p 200V NP0 5% 5mm Top
C231 Variant dependent, see separate list Top
C232 Variant dependent, see separate list Top
C233 Variant dependent, see separate list Top
C234 - Not used Top
C235 - Not used Top
C236 150p500VK20005%5 Capacitor ceramic 150p 500V K2000 5% 5mm Top
C237 150p500VK20005%5 Capacitor ceramic 150p 500V K2000 5% 5mm Top
C238 Variant dependent, see separate list Top
C401 47u25V Capacitor electrolytic 47u 25V 5mm Top
C402 47u25V Capacitor electrolytic 47u 25V 5mm Top
C403 47u25V Capacitor electrolytic 47u 25V 5mm Top
C404 47u25V Capacitor electrolytic 47u 25V 5mm Top
C405 47u25V Capacitor electrolytic 47u 25V 5mm Top
C406 47u25V Capacitor electrolytic 47u 25V 5mm Top
C407 47u25V Capacitor electrolytic 47u 25V 5mm Top
C408 47u25V Capacitor electrolytic 47u 25V 5mm Top
C500 2200u40V18x30A Capacitor electrolytic 2200u 40V 18x30mm axial Top
C501 4n7Y10 Capacitor 4n7 Y2 metallized paper 10mm Top
C502 4n7Y10 Capacitor 4n7 Y2 metallized paper 10mm Top
C503 47nX15 Capacitor 47n X2 metallized paper 10mm Top
C504 100u50V Capacitor electrolytic 100u 50V 5mm Top
C510 330n63VMMK5 Capacitor polyester 330n 63V MMK 5mm Top
D1 1N4004 Diode power 1N4004 Top

Other manuals for Lab.gruppen ACN 2C

Preview: Specifications
Specifications1 page

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lab.gruppen ACN 2C and is the answer not in the manual?

Lab.gruppen ACN 2C Specifications

ACN 2C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies80, 160, 250, 330, 400, 500, 600, 660, 800, 840, 950, 1000, 1100, 1200, 1300 and 1400 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 2S

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies40, 50, 60, 65, 75, 82, 90, 100, 110, 115, 125, 135, 140, 150, 160 and 165 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")

ACN 3C

Filters IconFilters
filter type4-pole, state variable
slope24 dB/octave
subsonic speaker protectionHigh-pass Filter at 40 Hz and 18 dB/octave
Crossover Frequencies IconCrossover Frequencies
crossover frequencies lo-mid80, 125, 170, 200, 250, 300, 350, 400, 440, 480, 530, 580, 620, 660, 700, and 7 Hz
crossover frequencies mid-hi500, 800, 1000, 1300, 1600, 2000, 2300, 2500, 2800, 3000, 3300, 3700, 4000, 4300, 4600 and 4800 Hz
Input IconInput
max input level20 dBu
input impedance20 kohms
Output IconOutput
max output level20 dBu in 5 kohms
gainadjustable ±8 dBu
max output level in 600 ohms17 dBu
Distortion and Dynamic Range IconDistortion and Dynamic Range
TDH at 0 dBu0.02% typically
dynamic range110 dB
Power Supply IconPower Supply
power supply voltage220 V - 110 V
power supply frequency50-60 Hz
Overall Dimensions IconOverall Dimensions
width483 mm (19")
height44 mm (1¾")
depth135 mm (5.3")
